Description
* Whole frame strong, stable, long-life securely machine.
* Precision machine parts, stable and durable performance.
* Neat appearance, fast and efficient.
* Easy to operate.
* Only need to adjust the handle when change difference size carton
* It can be connected with another carton sealing machine ,such as: FXJ6050, FXJ5050B, FXJ5050Z and other online implementations edge sealing seams and corners of the production line, the outlet can be used with strapping or film wrapping machines online. Achieve multifunctional production line.
* Whole line is using the "L"-style forward into the turn.
It is widely used in food, beverage, printing, pharmaceuticals, metal industries carton packaging. Its packaging fast, high-volume production to meet demand, while stabilizing sealing quality, sealing with neat appearance. And low cost of packaging, the majority of users.
The main technical parameters:
|
Model |
FXS7050 |
|
Voltage |
AC220V/380V 50Hz/60 Hz |
|
Working compressor (Kg/cm2) ) |
5.5~6 |
|
Sealing speed (m/min) |
8-10 |
|
Suitable tape(mm) |
W(48、60、72)×L1000 |
|
Table height(mm) |
550～630 |
|
Min. sealing size (mm) |
L320×W200×H180 |
|
Max. sealing size(mm) |
L700×W500×H500 |
|
Dimension (mm) |
L1190×W1130×H1530 |
|
Weight(Kg) |
390 |
New series of carton sealing machine are mainly used when sealing and packaging carton either individually or as part of a production line depending on the unit required. These sealers are widely used in the fields of electrical domestic appliances, textiles, foodstuffs, general merchandise, medicine’s, chemical industry as well as numerous others.
Quickly finish sealing& very economic & easily adjust
Up& down sealing
Smooth feeding ＆perfect sealing ( tidy, firm, no tearing the box)
Machine specification:
|
Model |
FXC5050 |
|
Sealing capacity |
about 1,000 standard cases per hour |
|
Adhesive tape used |
BOPP, water-free adhesive Tape, PVC adhesive tape |
|
Width of adhesive tape |
48,60mm |
|
Power sources |
220V, 50Hz, 180W |
|
Max. sealing dimensions (W*H) |
500* 500mm |
|
Min. sealing dimensions (W*H) |
120*110mm |
