Troubleshooting to common failures of strapping machine

Troubleshooting to common failures of strapping machine:

The strapper or baler, which is what we often call the strapping machine, has a strapping function, which can solve the packaging problems in our production and packaging. The products that have been packaged by the baler are not easy to deform and are beneficial to transportation and handling. The baler is also ours Many companies are indispensable packaging equipment, but when we use the packaging machine, we will inevitably encounter the failure of the packaging machine, so when we encounter the packaging machine failure, how should we solve it? The following editor of McGonagall will briefly talk about the common faults and solutions of the packer:

Common faults of the strapping machine, how about the baler does not automatically cut the belt? How to solve it?

1. The middle knife bearing is broken.
Check the reason, replace the bearing

2. Wear of the middle knife. .
The middle knife has cutting edges on both sides, one side can be worn and the other side can be used or replaced with a new knife.

3. The tube pin of the middle knife is broken.
Use a small punch to punch out the broken pin and install a new pipe pin.

4. The tightening force of the baler is adjusted too tightly.
There is a hexagon socket set screw on the adjusting nut. After loosening, turn the adjusting nut counterclockwise. After adjusting, tighten the hexagon socket set screw.

5. There is oil on the slippery sheet or the tightened drive belt.
Remove the slippery sheet to remove the oil, wipe it dry, and then assemble it in order.

6. The drive belt is too loose.
Adjust the transmission frame seat (Tigong) downwards or adjust the motor backwards to tighten the belt.

7. The thickness of the packaging tape is too thin or the gap between the unwinding rollers is too large.
The gap between the unwinding rollers should be only 0.05-0.1mm larger than the thickness of the belt, and adjust according to this requirement.

8. The magnetron (cut tape sensor) is faulty, and the magnetic sheet is off or damaged.

9. The balance position of the crossbar is not adjusted properly.

The above introduces the common failures of the baler. When the baler does not automatically cut the belt, our solution, there are many common failures of the baler, and the solutions are different for different failure problems. If your baler fails, If your own maintenance personnel cannot solve it, it is best to find a supplier to solve it, or you can call our hotline, and we will solve your problem for you!
