Description
KSZ-90 Horizontal Automatic cartoning Machine
Introduction:
Automatic cartoning machine is a packaging equipment, which fill products into carton automatically. The machine is combined the function, feeding boxes, forming box, folding leaflet, encasing products and leaflets into carton, printing batch number, sealing boxes, rejecting and transferring final product out. The machine can reduce the working intensity and save labor force cost; and production effectively. The machine is widely applied to carton case packaging in Pharmaceutical, Food, Cosmetic, Stationery, hardware, and ETC.
Product Feature:
1.International famous brand of electrical component such as PLC touch screen, frequency inverters, etc.
2.Adopt human-machine operation system.
3.Automatically stop when machine is overload.
4.Automatically reject lacking of package product and leaflet.
5.Automatically display trouble, Alarm and count finished products.
6.Stable performance, operation is easy.
Technical Specification:
|
Item |
Parameters |
|
|
Encasing speed |
30-90 boxes/min |
|
|
Box |
Quality requirement |
250-350g/㎡ (Base on carton size) |
|
Dimension range (L×W×H) |
(65-125)mm×(35-90)mm×(12-60)mm |
|
|
Leaflet |
Quality requirement |
60-70g/㎡ |
|
Unfolded leaflet specification (L×W) |
(80-250)㎜×(90-170)㎜ |
|
|
Fold range (L×W) |
(1-4)Fold |
|
|
Compressed air |
Working pressure |
≥0.6mpa |
|
Air consumption |
120-160L/min |
|
|
Power supply |
220V 50HZ |
|
|
Main motor power |
0.75kw |
|
|
Machine dimension(L×W×H) |
1265㎜×1135㎜×1640㎜ |
|
|
Machine weight |
about 1000kg |
|
