DXDG Series Automatic Ointment Packing Machine
Product Feature:
This machine is suitable for packaging of soft bags of sauce and ointment products in the field of food seasoning, daily chemical and medicine etc. It adopts step-less bag length adjustment. It’s suitable for single Paper/PE, Cellophane/PE, Plated aluminum/PE, BOPP/PE, Nylon/PE, and other heat-able sealed laminated film as packaging material.
Technical Specification:
|
Model |
DXDG-20II |
DXDG-50II |
|
|
Voltage (V/HZ) |
AC 220V/50HZ, or 110V/60HZ |
||
|
Power (W) |
1300 |
||
|
Packing volume (ml) |
5-20 |
10-50 |
|
|
Packing speed (bags/min) |
50-200 |
40-70 |
|
|
Bag width (mm) |
30-80 |
30-110 |
|
|
Bag length (mm) |
50-110 |
80-150 |
|
|
Dimension (L x W x H) mm |
790×600×1780 |
800×700×1900 |
|
|
Net Weight (Kgs) |
350 |
400 |
|
|
Model |
DXDG-100II |
DXDG-500II |
DXDG-1000II |
|
Voltage (V/HZ) |
AC 220V/50HZ, or 110V/60HZ |
||
|
Power (W) |
1700 |
1500 |
1700 |
|
Packing volume (ml) |
20-100 |
50-500 |
100-1000 |
|
Packing speed (bags/min) |
30-70 |
25-60 |
|
|
Bag width (mm) |
30-150 |
30-150 |
50-220 |
|
Bag length (mm) |
80-220 |
50-220 |
50-250 |
|
Dimension (L x W x H) mm |
1002×860×2000 |
||
|
Net Weight (Kgs) |
500 |
||
